Pile Turner For Paper Automatic And Plastic Turning Stacker
Electric 2900*2200*2200mm
Function:
Replace the tray, align the paper, Remove dust from paper, loosen
the paper, dry, Neutralize odors, take out the damaged paper,
center, and adjust the temperature, humidity and air volume.
This machie is mainly used in printing and packing industry ,for
pile turning aligning ,dust removal etc. It is a necessary
equipment to improve the work efficiency and printing quality.
| Technical Parameter |
| Model | PT1300 | PT1450 | PT1650 | PT1900 |
| Maximum paper size(mm) | 800*1300 | 1100*1450 | 1200*1700 | 1400*850 |
| Minimum paper size(mm) | 500*600 | 500*600 | 500*600 | 500*600 |
| Power supply | 3P 380V AC 50HZ |
| Machine weight(kg) | 3500 | 4800 | 6500 | 8000 |
| Max. weight of paper pile(kg) | 1000 | 1400 | 2500 | 3000 |
| Paper pile height(mm) | 800-1600 | 850-1600 | 850-1600 | 900-1600 |
| Total machine power(kw) | 10 | 12 | 14 | 22 |
| Machine size(mm) | 10600*2400*2750mm | 11400*2600*2950mm | 1300*2700*2950mm | 13800*2900*2950 |
1. Operability: two operation panels make manual operation more
convenient.
The operation panel on the pile turner enables people to control
the operation process of the machine more intuitively and
conveniently:
Control the wind volume, align the paper pile back and forth,
adjust the clamping force and shaking force of the paper pile, etc.
2. Hydraulic system: temperature control device is used to prevent
the instability of hydraulic system in high temperature season and
cold season.
Performance characteristics
1. Flip the paper pile to replace the tray
Flip the original tray onto the top of the paper pile through the
flip function, which is convenient to manually take out the
original tray and replace it with other trays. Then flip the paper
pile back to its original position with the flip function
(especially when the paper pile is purchased and the tray is made
of wood).
2. Align the paper, Remove dust from paper, loosen the paper, dry,
Neutralize odors, take out the damaged paper, center, and adjust
the temperature, humidity and air volume, replace the tray.
3. The machine can efficiently align the paper pile (about 3
minutes).
4. Automatic paper pile feeding and output function (optional).
Company Information
*With 10 years' Experience
*Having ISO 9001-Certified Factory
*Strong R&D capability
*High Quality Guaranteed
*First Class Service And Best Prices
*Primary products:
Automatic High Speed Flute Laminater
ZXSCM book case making machine
650UV Coating Machine
ZX-650C Manual Paper Pasting Machine
Box Making Machine
Hot Melt Gluing Machine and Gluing Machine
Table Gluing Machine
Paper Pressing Machine.etc
Welcome to visit our factory!
FAQ:
Q1: Are you a manufacturer?
Yes, we are specialized manufacturer of hot foil stamping machine
and die cutting machine in China over 20 years.
Q2: Do you have stock products to sell?
We manufacture machines in batch. So most of machines have in
stock, please check with us before ordering.
Q3: How about installation and training?
Installation and training: If purchaser's engineer travels at own
cost to China, free training session. If engineer sent to
purchaser's factory, all travel cost paid by purchaser.
Q4: How about warranty?
Warranty period: 12 months from the shipping date of machine.
Warranty will be not valid if machine subject to misuse or
accidental damage or operator's error. During the valid time, we
will supply spare parts. If you have any other questions, pls
contact us and we will reply you through product's photos and
videos to make every detail clear.
Why choose us?
1.Our brand "INNOVO" is well-known in our domestic market and over
80 countries and territories. Europe, South America, Latin America,
Southeast Asia, Middle East, Africa etc.
2.Genuine products with excellent quality. Company has always
proved the 100% quality.
3.After-sales service and technical assistance: company provides
after sales service and technical assistance as per customers'
requirement and needs. After-sales service provided engineers
available to service machinery overseas.
4.Cost saving: lon-life, shock resistant and high reliability
bearings with excellent quality and better performance, resulting
in increased cost saving.
5.Less cost of purchase: We are the manufacturer directly.
6.Attendant customers queries promptly.
